Table Type Spot Welding & Brazing Machine | ¡@ |
|
|
|
SD20A | SD20F | SD40A |
|
The force system combined with hardened slide, stroke bearings and coil spring, providing smooth and rapid follow up movement.(air operated type only) |
Foot operated type with force-firing design, welding force can be set precisely. | |
Spot welding mode or brazing mode selectable. | |
Digital format pre-setting & synchronous welding control ensure consistent & precise welding. | |
All solid state welding control & modular design simplifies maintenance. | |
Synchronous SCR contactor with protection thermostat. | |
¡@ |
Specifications¡G |
Model |
Rated |
Welding |
Control Power |
Rated Frequency |
Rated
Max. |
Max. Short Current |
Duty Cycle |
Throat |
Max. Electrode Force |
Electrode Stroke |
Electrode Diameter |
Cooling Water |
Net Weight |
|
Opening |
Depth |
|||||||||||||
KVA |
V |
V |
Hz |
KVA |
A |
% |
mm |
mm |
kgf |
mm |
mm£p |
l/min |
kg |
|
SD20F |
20 |
220 |
220 |
50 60 |
50 60 |
13,500 |
8.0 6.0 |
95 |
200 |
100 |
35 |
12 |
3 |
170 |
SD20A |
20 |
220 |
220 |
50 60 |
50 60 |
13,500 |
8.0 6.0 |
115 |
185 |
150 |
35 |
12 |
3 |
185 |
SD40A |
40 |
220 |
220 |
50 60 |
83 100 |
17,000 |
10.0 8.0 |
190 |
200 |
150 |
35 |
16 |
6 |
300 |
SD50A |
50 |
220 |
220 |
50 60 |
92 110 |
19,000 |
12.0 10.0 |
190 |
200 |
150 |
35 |
16 |
6 |
330 |
¡@
