| Magnet Wire Welder | ˇ@ |
 |
|
SMA01H91F |
 |
 |
 |
| SpecificationsˇG |
|
Model |
Rated Capacity |
Supply Power |
Rated Frequency |
Rated Max Input |
Max. Short Current |
Duty Cycle |
Throat Dimensions |
Max. Electrode Force |
Electrode Stroke |
Electrode Diameter |
Net Weight |
External dimensions |
|||
|
Opening |
Depth |
W |
D |
H |
|||||||||||
|
KVA |
V |
Hz |
KVA |
A |
% |
mm |
mm |
kgf |
mm |
mmØ |
kg |
mm |
mm |
mm |
|
|
SMA01H91F |
1 |
220 |
50 |
4 |
2000 |
3.2 |
35 |
130 |
1 |
15 |
3.2 |
57 |
600 |
750 |
1060 |
